AZ-600 Exam Questions & Answers

Correct Answer: B

Instead: Solution: You run the nslookup AzS-ERCS01.azurestack.local command.

Note: nslookup is a network administration command-line tool for querying the Domain Name System to obtain the mapping between domain name and IP address, or other DNS records.

ASDK architecture, Virtual machine roles

The ASDK offers services using the following VMs hosted on the development kit host computer:

* AzS-ERCS01 - Emergency Recovery Console VM.

Reference:

https://docs.microsoft.com/en-us/azure-stack/asdk/asdk-architecture?view=azs-2008

Correct Answer:

Box 1: Register-CustomDnsServer

Resolving external DNS names from Azure Stack Hub To resolve DNS names for endpoints outside Azure Stack Hub (for example:

www.bing.com), you need to provide DNS servers that Azure Stack Hub can use to forward DNS requests for which Azure Stack Hub isn't authoritative. For deployment, DNS servers that Azure Stack Hub forwards requests to are required in

the Deployment Worksheet (in the DNS Forwarder field). Provide at least two servers in this field for fault tolerance. Without these values, Azure Stack Hub deployment fails.

Configure conditional DNS forwarding

Important

This only applies to an AD FS deployment.

To enable name resolution with your existing DNS infrastructure, configure conditional forwarding.

To add a conditional forwarder, you must use the privileged endpoint.

For this procedure, use a computer in your datacenter network that can communicate with the privileged endpoint in Azure Stack Hub.

1.

Open an elevated Windows PowerShell session (run as administrator), and connect to the IP address of the privileged endpoint. Use the credentials for CloudAdmin authentication.

$cred=Get-Credential Enter-PSSession -ComputerName -ConfigurationName PrivilegedEndpoint -Credential $cred

2.

After you connect to the privileged endpoint, run the following PowerShell command. Substitute the sample values provided with your domain name and IP addresses of the DNS servers you want to use.

Register-CustomDnsServer -CustomDomainName "contoso.com" - CustomDnsIPAddresses "192.168.1.1","192.168.1.2"

Box 2: fabrikam.com

The external DNS zone.

Box 3: "192.160.20.1", "192.160.20.2",

The IP addresses for the DNS servers in External DNS zone.

Correct Answer:

Step 1: Connect to the Hardware Lifecycle Host (HLH) Create the OAW VM using a script

The following script prepares the virtual machine as the Operator Access Workstation (OAW), which is used to access Microsoft Azure Stack Hub.

Sign in to the HLH with your credentials. (Step 1) Download OAW.zip and extract the files. (Step 2) Open an elevated PowerShell session. (Step 3)

Navigate to the extracted contents of the OAW.zip file.

Run the New-OAW.ps1 script.

Step 2: From microsoft.com, download the OAW.zip file and extract the contents Download files

Because of the stateless nature of the solution, there are no updates for the OAW VM. For each milestone, a new version of the VM image file is released. Use the latest version to create a new OAW VM. The image file is based on the latest

Windows Server 2019 version. After installation, you can apply updates, including any critical updates, using Windows Update.

Validate the hash of the downloaded OAW.zip file to make sure it hasn't been modified before using it to create the OAW VM.

Step 3: From an elevated PowerShell session, run the New-OAW.ps1 script.
