VCP-510 Online Practice Questions and Answers

An administrator is troubleshooting an ESXi 5.x host and needs to export diagnostic information. The host is currently managed by a vCenter Server instance. Which two ways can the information be gathered using the vSphere Client? (Choose two.)

A. Select Home. Under Administration, click System Logs and click the Export System Logs button. Select the affected ESXi host. Select Select All. Select a location and click Finish.

B. In the vSphere Client, select the affected ESXi host. Right-click the host and select Export Diagnostic Data. Select a location and click OK.

C. Log in to the ESXi host locally, Select Export System Logs.

D. In the vSphere Client, select the affected ESXi host. Select File, Export and Export System Logs. Select Select All. Select a location and click Finish.

A vSphere 5 implementation consists of a fully automated DRS cluster with two ESXi 5.x hosts with the following vSphere Standard Switch configuration.

1.

Switch A . three vmnics, one port group named sFTP-PG

2.

Switch B . two vmnic, one port group named Web-PG

3.

All vmnics are trunked to the same physical switch.

DRS has been configured with an anti-affinity rule for all virtual machines in the Web-PG so that no more than half of the virtual machines run on any given host. The virtual machines on WebPG are experiencing significant network latency. The network team has determined that a performance bottleneck is occurring at the ESXi host level. Which solution will require the least amount of administrative work and the least amount of service interruption?

A. Migrate Web-PG to Switch A and sFTP-PG to Switch B on each host

B. Move a vmnic from Switch A to Switch B on each host

C. Convert the three Switch Bs to a single vSphere Distributed Switch

D. Use vMotion to redistribute some of the VMs in Web-PG to a different ESXi host

What are two reasons creating a host profile could fail? (Choose two.)

A. Selecting a VMware Infrastructure 3.5 host

B. The host selected is currently in maintenance mode

C. Special characters were used when naming vSphere objects

D. Evaluation Licenses are being used

vCenter Server is running in a virtual machine that is part of a vSphere DRS cluster. The vCenter Server virtual machine has been tested and can successfully migrate with vMotion between all ESXi hosts in the cluster. DRS is configured for partial automation. What happens if an ESXi 5.x host that is running the vCenter Server virtual machine experiences a power outage?

A. All DRS cluster operations will be unavailable until the failed ESXi host is brought back online.

B. vCenter Server will remain offline, but all virtual machines on the remaining hosts will continue without interruption.

C. This situation cannot occur, because vCenter Server cannot be installed on a virtual machine in a vSphere DRS cluster.

D. vSphere will restart the vCenter Server virtual machine on another host.

What are two reasons why a company would choose to use ESXi 5.x instead of using VMware Workstation 8? (Choose two.)

A. The company needs to be able to assign existing physical disks to virtual machines.

B. The company needs remote management of virtual machines

C. The company needs support for virtual machines with up to sixteen vCPUs

D. The company wants the lowest overhead possible for the virtual infrastructure.

An administrator plans to deploy ESXi 5.x on a blade server containing no local disks. What boot options are supported for use in place of local disks? (Choose three.)

A. An SD card

B. A NIC with iBFT

C. Auto Deploy

D. A server with IPMI or iLO

E. A dedicated NFS share

An existing vSphere 4 environment will be upgraded to vSphere 5.x. The current implementation utilizes ESXi 4.1 and the new implementation will use ESXi 5.x. In which two ways will the new ESXi 5.x implementation differ from the ESXi 4.1 implementation? (Choose two.)

A. VMware ESXi 5.x provides a host-based firewall.

B. VMware ESXi 5.x can boot from additional local sources such as a USB drive.

C. VMware ESXi 5.x can be managed from a web browser.

D. VMware ESXi 5.x can support virtual machines with larger hard drive configurations.

Which two storage adapters require no VMkernel ports? (Choose two.)

A. Independent Hardware iSCSI Adapter

B. iSCSI Software Adapter

C. Dependent iSCSI Adapter

D. Fibre Channel HBA

Why is converting a virtual machine to a template significantly faster than creating a clone of the virtual machine?

A. Making a clone creates a linked-mode virtual disk.

B. Making a clone creates a full copy of the VMDK file.

C. Making a clone only creates a copy of the .vmx file.

D. The template conversion has low priority on the system CPU.

What would cause the proportional share mechanism to be invoked?

A. There is resource contention

B. CPU ready time exceeds a threshold

C. More than 1 virtual machine is running

D. the sum of reservations exceeds the physical resources
