HPE6-A80 Online Practice Questions and Answers

A mall requires a wireless network upgrade to 802 -Max The company that owns the mall wants to provide the APs for the entire mall. However, several of the larger national chain retailers with spaces in the mall want to offer wireless services with their own SSIDs. These individual retailers also have their own wireless guest services and wireless client devices They have their own corporate infrastructure and want to handle all of this wireless traffic on their own, including terminating the traffic on their own controllers. The mall requires redundancy for its services, out the retailers do not.

Which plan for mobility controllers (MCs) and mobility master (MW) meets the needs of this scenario?

A. a pair of MMs for the mall company, but not MCs: MMs control one MC for each retailer with its own SSIDs

B. two MCs for the mall company and for all of the retailers, both controlled by the same pair of MMs

C. two MCs for the mail company controlled by a pair of MMS; one standalone MC for each retailer with its own SSIDS

D. two MCs for the mall company and one MC for each retailer with its own SSIDs, all controlled by the same pair of MMs

Refer to the exhibit.

The exhibit shows the current AP deployment in a school. This customer indicates that the current wireless performance is inadequate and w B02.11ax. For the new' solution, what should the network architect recommend?

A. APs deployed in rooms with a density-based design

B. APs deployed in similar locations, but with dual 5 GHz radios

C. APS deployed in similar locations, but with higher gain antennas

D. APs deployed in hallways with about twice the density

Refer to the exhibit.

A stadium wants to deploy location-based services, including blue-dot wayfinding over a 200.000 square root (isr580 sq. m) area. The custom past particular areas. The customer has selected a 1 year subscription.

The exhibit shows the BOM that the architect created in iris.

Which correction should the architect make?

A. Change the campaign subscription to a Maps subscription.

B. Add two Maps subscriptions.

C. Add another campaign subscription.

D. Remove one Blue Dot Nav subscription.

Refer to the exhibit.

A customer has an existing network with ArubaOS switches, Aruba 7205 controller, and 802.11ac APs. The customer needs a wired upgrade for their campus network and wireless upgrade with 802,11ax APs and would like to get all the

functions of AP.

The customer has one building with 3 floors with the following wired devices,

*

8 printers

*

security cameras

The architect plans to propose 75 AP-535s.

The security cameras are a high definition pan-tilt-zoom with heaters for harsh environments that require more than 45 W to function,

Which exhibit shows an access switch mat meets the customer needs?

A.

Option A

B.

Option B

C.

Option C

D.

Option D

A company already has an Aruba wireless network The network currently consists of: * oneMM-HW-1k

*

two 7210 MCs in the network core

*

two 721GMCsintheDMZ

*

200 AP-515S in Building 1 and Building 5

100 AP-515S each In Building 2r Building 3, and Building 4

The customer now wants to assess if it needs local Mobility controllers (MC) for any buildings:

- Building 1 is the main office building for the campus. It supports the highest number of APs. It connects to the network core without an aggregation layer.

*

Building 2 is further away from the Building i. and no roaming is provided between it and the other buildings its access layer connects to the network cone with a pair of Aruba CX 6300M aggregation switches.

*

Building 3 is further away from the other buildings, it connects to the network core without an aggregation layer.

The Guest SSID traffic should be tunnelled to the DMZ controllers

' Building 4 has its own local datacenter and Internet connection. The company would like it to be able to operate completely autonomously if its aggregation layer loses connectivity with the core.

*

Building 5 is further away from the other buildings, it connects to the network core without an aggregation layer.

This building has been assigned to a partner that would like to manage a dedicated SS1D using the shared AP infrastructure.

In which two buildings should the network architect plan local mobility controllers (MCs)? (Select two)

A.

Building 1

B.

Building 4

C.

Building 5

D.

Building 3

E.

Building 2

For which scenario do Aruba CX 6300M Series switches meet the needs for an upgrade of the wired access layer while the Aruba CX 630QF Series switches do not?

A. The customer wants to utilize the Aruba AP-515 support for 002 3bz connectivity.

B. The customer wants to utilize LACP on AP515 in VSF switch configuration.

C. The Aruba CX6300M supports 10GBase-T connectivity with AP-515.

D. The Aruba CX 630DM support up to 75W PoE+ per port

Refer to the exhibit.

A museum wants to add full S02.11ax wireless coverage across the building, which is about 210 feet (64 m) by 330 feet (100 m). The museum has 15-foot (4.6 m) ceilings and stone interior walls. The network needs to support up to 600

wireless guest devices

The exhibit also shows a preliminary plan tor AP locations, me museum has eight Ethernet drops in the lobby and girt stop, but has otherwise not been wired.

What is one recommendation that the architect should make to ensure a successful deployment?

A. Add about 10 APs to achieve adequate density

B. Use directional antennas to avoid lost signal.

C. Use at least CATS cable to connect to the APs.

D. Add a wiring closet closer to the north side.

The architect plans to recommend an upgrade to Aruba CX switches What is one requirement for the new solution that justifies this recommendation?

A. the requirement to support secure IPsec tunneling at the aggregation layer

B. the requirement to support larger ARP tables at the aggregation layer

C. the requirement to support smart Rate at the access layer

D. the requirement to support tunneled-node at the access layer

A customer has an Aruba solution with APs, MCs, and an MM The customer also uses AirWave and ClearPass. The customer wants to add Aruba CX Switches, which use per- user tunneled node, to the solution. How should the Aruba CX Switches integrate with the existing solution in order to determine when to tunnel device traffic to MCs?

A. They should be managed by AirWave with SNMPv3.

B. They should implement authentication to ClearPass.

C. They should be directed to MCs by a DHCP or DNS server.

D. They should be manually added as MDs in MM.

A retailer currently has two redundant ClearPass C2000 0L36O Gen9 hardware appliances and two perpetual 1K Access licenses. The customer uses ClearPass to authenticate employee wireless devices and other corporate wireless devices. ClearPass togs indicate that, peak license usage is currently 1900.

The customer now wants to add a guest access solution. Guests will connect to an open SSiD and be redirected to a portal which they can use to self-register and log in. The customer anticipates that up to f 550 guest devices will connect at the same time.

The customer requires the most cost-effective solution that will meet the requirements. What should the network architect recommend for this solution?

A. IK + 500 Access licenses: IK + 500 Guest licenses

B. 1K + 500 Access licenses; Two 1K Onboard licenses

C. 1K + 500 Access licenses

D. Two 1K Guest licenses
