Refer to the exhibit.
Based on the Policy configuration shown, which VLAN will be assigned when a user with ClearPass role Engineer authenticates to the network successfully on Saturday using connection protocol WEBAUTH?
A. Deny Access
B. Employee VLAN
C. Internet VLAN
D. Full Access VLAN
Refer to the exhibit.
A company has attempted to implement OSPF without success. The devices in Area I need to be able to reach Area 2. Routes should be aggregated for advertisement in other areas. What must be changed to meet these requirements?
A. Change Area 3 to Area 0; remove Area 1 from Switch-2 and Area 2 from Switch-1.
B. Add the 10.2.0.0/16 range on Swttch-1 and the 10.1.0.0/16 range on Switch-2.
C. Add Area 1 and Area 2 on VIAN 100 on both Switch-1 and Switch-2. Remove Area 3.
D. Move the 10.1.0.0/16 range to Area 2 on Switch-1 and the 10.2.0.0/16rangetoArea 1 onSwitch-2.
A company has AOS-Switches, Aruba ClearPass, and Aruba Airwave. A network administrator needs to set up a new switch with the same settings found on other switches in the company. Which action rs likely to be the most useful to perform the task?
A. Access the Network Device view on ClearPass.
B. Use the configuration audit tool on AirWave.
C. View the current running config on each switch.
D. View usage patterns on the switches on AirWave.
Refer to the exhibit.
The network administrator needs to set up BGP between the two company switches. Switch-1 and Switch
2. The BGP connection does not establish. Based on the exhibits, what does the administrator need to do to fix the issue?
A. Enable the multihop option for the neighbor on each of the switches.
B. Enter the network command for 10.0.0.0/24 in the router BGP mode on each switch.
C. Enable BGP on the interfaces that the switches use to reach each other.
D. Set the update source for the neighbor to the local loopback interface on each switch.
When is it necessary to use an SNMP based Enforcement profile to send a VIAN?
A. When we have to assign a vlan to a wired user on a third party wired switch that doesn't support RADIUS return attributes.
B. When we have to assign a VLAN to a wired user on an Aruba Mobility Access Switch.
C. When we have to assign a VIAN to a wired user on an Aruba Mobility Controller.
D. When we have to assign a VLAN to a wired user on a third party wired switch that doesn't support RADIUS authentication.
E. When we have to assign a VLAN to a wireless user on an Aruba Mobility Controller.
What is true about clustering and AP connections to cluster members?
A. The AP will always stay connected to the LMS IP address configured in the AP profile.
B. During rebalancing, the active load is redistributed first.
C. The default thresholds are 75% for the Rebalanced Threshold and 25% for the Unbalanced Threshold.
D. AP load balancing is disabled by default.
Refer to the exhibit.
Which statements accurately describe the status of the Onboarded devices in the configuration tor the network settings shown? (Select two.)
A. They will connect to Employee_Secure SSID after provisioning.
B. They will connect to Employee_Secure SSID for provisioning their devices.
C. They will use WPA2-PSK with AES when connecting to the SSID.
D. They will connect to secure_emp SSID after provisioning.
E. They will perform 802.1X authentication when connecting to the SSID.
An administrator implements a standalone controller that runs ArubaOS 8.x. Which feature should the administrator configure to optimize the RF operation for the company's WLAN?
A. AirMatch
B. Clustering
C. ARM
D. Zones
An administrator wants to implement bandwidth limits for guest users to restrict their Internet usage. On the Mobility Master (MM), where would the administrator define these limits?
A. User role
B. Firewall policy
C. AAA policy
D. 802.1X policy
A company has AOS-Switches deployed at sites with inexperienced IT staff. The main office network
administrators want to track if configurations change on branch switches.
What should be set up for this purpose?
A. an SNMP trap
B. an RMON alarm
C. an auto-config server
D. an lP SLA profile
