CPRE-FL Online Practice Questions and Answers

In order to document a door system for a underground railway system, the following activity diagram has been modelled. You reconcile this diagram with your notes. Which two of the following notes were not represented in the diagram? (1 Point)

Your notes:

A. Double pressing of the door button countermands the currently running action.

B. The tread is pulled in once the door is closed.

C. The light-emitting diode is deactivated at the end of the process.

D. If the door is open, it is subsequently closed.

E. If the door is closed, it is subsequently opened.

Which two statements are correct with regard to the introduction of a requirements engineering tool? (2 Points)

A. The introduction of a tool defines the future requirements engineering approach

B. Risks associated with the introduction can be identified through a pilot operation

C. The requirements engineering processes must be clearly defined before introduction

D. The license costs are generally the greatest cost block relating to the introduction of a requirements engineering tool

Sentence-templates can be used to document natural language requirements. You want to introduce such a sentence-template in your project and must convince your project manager of its advantages. Which two arguments do most likely put forward in this discussion? (2 Points)

A. High quality requirements are guaranteed already from the initial documentation.

B. Requirements that are formulated according to the sentence-template contain no linguistic transformation effects.

C. Drafting requirements in accordance with sentence-templates can be learned in a short time.

D. The use of a sentence-template basically delivers greater information content.

E. A requirement drafted according to a sentence-template satisfies all quality criteria for requirements.

You are to create a requirements specification for an internet banking software. The system shall perform bank credit transfers and therefore receives from the user, among other information, the bank identification code and the name of the bank. Now things have changed so that only the bank identification code must be entered by the user and the bank name is no longer required. On which part of your documentation do you most likely have to work in order to incorporate this change? (2 Points)

A. Nowhere, since this is a detail for the architecture.

B. In the chapter in which the states of the system are described.

C. As a change in the goals has been communicated, the goals in the specification must be updated.

D. If it is about inputs and outputs of the system, this change has to be worked into the context diagram.

E. You have to adjust the class model and/or the data model, which describe the structure of the system's input and output data.

Requirements documentation can either be natural language or model-based. Which two statements are most applicable? (2 Points)

A. If documentation is model-based, natural language documentation can be dispensed with.

B. As models are more formal, they offer a higher degree of uniqueness compared to natural language.

C. In requirements engineering models are more suitable than textual descriptions to reduce the complexity of the entity being considered.

D. When deciding between model-based and natural language documentation, model-based is preferable.

One task of the requirements engineer is negotiation of requirements. At this point, conflicts between the stakeholders may be discovered. These must then be resolved. In this process, a differentiation is made between various kinds of conflict. Which two of the listed conflicts are least suitable for handling by the requirements engineer? (1 Point)

A. Subject matter conflict

B. Value conflict

C. Architectural conflict

D. Cost conflict

E. Structural conflict

Validating requirements is one of the main activities of requirements engineering. Which four of the following techniques are suitable for requirements validation? (2 Points)

A. Stakeholder analysis

B. Walk through

C. Ranking

D. Monitoring

E. Decomposition

F. Apprenticing

G. Generalization

H. Validation by using an interface prototype

I. Perspective-based reading

J. Inspection

K. Visualization

You have been commissioned to analyze a change request for its possible impact. Which of the following aspects must be analyzed for this? (2 Points)

A. B, C, E, G

Which of the following statements best characterizes the relationship between a requirements engineer and a stakeholder in the role of a tester? (1 Point)

A. The requirements engineer delivers input for the work of the stakeholder.

B. The output from the requirements engineer is managed by the stakeholder.

C. The stakeholder delivers input for the requirements engineer.

D. The stakeholder monitors the work of the requirements engineer.

E. The work of the requirements engineer is not related to the role of the stakeholder.

You model invoices and invoice items with a UML class diagram. The total amount of an invoice is calculated by summing up all individual invoice items. This means that an invoice showing 5 article prices contains 5 invoice items. What model element most accurately describes the relationship between invoice and invoice items? (1 Point)

A. Composition

B. Aggregation

C. Generalisation

D. Association
