301A Online Practice Questions and Answers

An LTM Specialist needs to gather website statistics such as latency and throughput on the existing virtual

server. This virtual server load Balances the backend web servers.

Which F5 feature will provide this?

A. the Performance panel

B. the AVR module

C. the Dashboard

D. the Statistics panel

An LTM Specialist needs to load balance an application using an LTM device to meet the requirements:

1.

The application servers do NOT Support SSL, but client access to the application should be secured.

2.

Multiple requests from the same client should be sent to the same pool member.

3.

All pool members will have roughly the same processing power, and traffic should be distributed evenly.

The LTM device is NOT the pool members' default gateway. Which configuration should the LTM Specialist.

A. a performance 14 virtual server with a SNAT and cookie persistence

B. a performance L4 virtual server with a Client SSL profile and Source Address persistence

C. A performance L4 virtual server with a SNAT, HTTP profile. Server SSL profile, and cookie persistence

D. A standard virtual server with a SNAT, HTTP profile Server SSL profile, and cookie persistence

E. A standard virtual server with a SNAT, HTTP profile, Client profile, andd cookie persistance.

A virtual server is experiencing intermittent port exhaustion. What should be done to fix this issue?

A. add more SNAT addresses

B. add more pool members

C. enable advanced routing

D. enable SNAT automap

An LTM Specialist needs to provide statistics regarding the round-trip time between the clients and the

servers.

Which metric should be part of the analytics profile to provide that information?

A. Page Load Time

B. User Sessions

C. Max TPS and Throughout

D. Response Codes

Consider the monitor configuration displayed below.

What is the status of a pool member that responds with ''200 OK''?

A. available

B. down

C. disabled

D. unknown

A web server's default gateway is the network router. The LTM Specialist needs to introduce an LTM device to load balance to the web servers without changing the server's default gateway. Which deployment method and settings should the LTM Specialist use to ensure correct traffic flow and that the web servers can obtain the actual con IP addresses?

A. route deployment with Automap configured and X-Forwarded-For inserted in HTTP headers

B. route deployment without SNAT configuration

C. SNAT deployment with automap configured and X-Forwarded-For inserted in HTTP headers

D. SNAT deployment with automap configured

Exhibit.

The server team has recently configured the three new DNS servers shown for the data center. No current DNS servers are currently configured on the LTM device. Which command should be used to configure the LTM device to use the new DNS servers?

A. tmsh create/systins name-servers add {192 168.1.2.192.168.100.1O0.192.168.2O0.2OO}

B. tmsh change /sysdns name-servers add {192.168.1.2.192.168.100.100.192.168.200.200}

C. tmsh modify/sysdns name-servers add {192.168.1.2.192.168.100.100.192.168.200.200}

D. tmsh set/sysdns name-servers add {192.168.2.192.168.100.100.192.168.200.200}

An LTM is configure an application that is separated into several subdomains across multiple virtual servers. Many of these subdomains require encryption and could be accessed by anyone on the internet. The configuration must NOT result in SSL warnings to end users. How should the LTM Specialist configure the SSL profiles for these virtual servers?

A. Obtain an SSL certificate for each subdomain, make a ServerSSL profile for each subdomain, and apply to the related SSL Virtual Server.

B. Obtain a wildcard certificate, create one ClientSSL profile and apply to all SSL Virtual Servers

C. Create a self-singed SSL certificate for each subdomain make a ClientSSL profile for each subdomain, and apply to the related SSL Virtual server

D. Create a self-singed SSL certificate for each subdomain make a Client profile for each SSL Virtual Server

An LTM Specialist needs to use the tmsh command to create a pool named http_pool with member

10.10.101:80

on an LTM device. Which expression should the LTM Specialist use?

A.

# tmsh create pool http_pool members {10.10.10.101:80}

B.

# tmsh create pool http_pool members add {10.10.10.101:80}

C.

# tmsh create it pool http_pool members {10.10.10.101:80}

D.

# tmsh create itm pool http_pool member {10.10.10.101:80}

To improve application security, an LTM Specialist must configure a BIG application access. The BIG IP system to authenticate the client certificate before permitting application access. The BIG-IP system must also support the ability to red to redirect users to a certificate enrolment system without generating a browser error. Within the Client SSL profile, which value should the LTM Specialist select for the Client Certificate option?

A. Require

B. Request

C. Demand

D. ignore
